Relationship Between Story Drift Angle of Steel Frames and Maximum Edge Strain of Steel Beams
-
摘要: 抗震性能化设计需要对耗能构件内出现的最大应变进行计算和限制。为研究钢框架梁的最大应变与框架层侧移角的关系,采用包含强化段的钢材应力-应变曲线,计入钢梁剪切变形,给定梁端截面最大应变,计算了4种钢材的钢梁端位移延性系数,指出基于设计标准中钢材名义最小强度计算的强屈比,给出的钢梁延性系数是不准确的。计入框架柱变形后给出了框架层延性系数,最后给出层间侧移角与梁端最大应变的关系曲线,并提出了近似公式;给出了剪切型耗能连梁按照弯曲型梁计算时与层间侧移角1/50对应的最大应变。Abstract: In performance-based seismic design, the maximum strain developed in energy-dissipating components must be calculated and checked against specified limits. To investigate the relationship between the maximum strain in steel beams and the story drift angle of steel frames, a stress-strain curve including the strain-hardening stage was adopted, and the shear deformation of steel beams was taken into account. Given the specified maximum strain at the beam-end section, the displacement ductility factors of the beam end were calculated for four types of steel. It was pointed out that the strength ratio computed from the nominal minimum strength specified in design codes led to inaccurate ductility factors of steel beams. After incorporating the deformation of columns, the story ductility factor of the frame was evaluated. Curves relating the story drift angle to the maximum strain at the beam end were presented, and an approximate formula was proposed. Furthermore, for shear-type energy-dissipating coupling beams, the maximum strain corresponding to a story drift angle of 1/50 was given when such beams were treated as flexural members.
-
Key words:
- story drift angle /
- strain /
- ductility factor /
- steel beam /
- frame
-
[1] 中华人民共和国住房和城乡建设部. 钢结构设计标准:GB 50017—2017[S]. 北京:中国建筑工业出版社, 2018. [2] European Committee for Standardization(CEN). Eurocode 8—design of structures for earthquake resistance:part 1-1. general rules and seismic action:EN 1998-1-1∶2024[S]. Brussels:CEN, 2024. [3] American Institute of Steel Construction. Seismic provisions for evaluation and retrofit of existing structural steel buildings:AI SC 341-22[S]. Chicago:American Institute of Steel Construction, 2022. [4] Tall Buildings Initiative. Guidelines for performance-based seismic design of tall buildings:version 2.03[R]. Berkeley:Pacific Earthquake Engineering Research Center, 2017. -
