Research on the Influence of Axial Compression Ratio on the Seismic Performance of Fully Bolted Octagonal Core-Tube Joints in Square Steel Tube Columns
-
摘要: 在实际工程中,钢柱往往会存在不同的竖向轴压比。为研究方钢管柱八边形芯筒全螺栓连接节点在不同轴压比下的力学性能,建立了竖向轴压比分别为-0.2、-0.1、0.0、0.1、0.2、0.3、0.4、0.5的8组有限元节点模型,分析了在双向水平加载下,不同轴压比对节点抗震性能的影响规律。结果表明:在受拉弯和纯弯作用时,节点最终表现为法兰高强螺栓受拉破坏;在受压弯作用时,当轴压比为0.1时,节点最终表现为法兰高强螺栓受拉破坏,当轴压比为0.2~0.5时,节点最终表现为下柱与柱脚加劲肋连接处破坏在受拉弯作用下,节点法兰板、法兰高强螺栓及芯筒下部承载较大,节点传递荷载能力较弱,往下柱传递荷载较小,节点法兰高强螺栓在罕遇地震作用下结构弹塑性层间位移角限值0.02 rad加载级时受拉变形过大导致节点破坏,实际工程对可能出现受拉或地震烈度过大的工况应重点关注法兰和高强螺栓的设计;在受纯弯和压弯作用下,随着轴压比增大,节点法兰板、法兰高强螺栓及芯筒下部承载减小,下柱承载增大,节点传递荷载能力增强、耗能能力及延性增大,但整体承载力减小、刚度退化加快;在轴压比为0时节点承载力最高,但耗能能力较弱,且最终发生节点破坏。节点设计时建议控制轴压比为0.2,使节点在具有较高承载力的同时也具有相对良好的延性耗能能力。Abstract: In practical engineering, steel columns are often subjected to different vertical axial compression ratios. To study the mechanical properties of the octagonal core tube full-bolted connection joints of square steel tube columns under different axial compression ratios, eight sets of finite element joint models were established, with axial compression ratios of vertical -0.2, -0.1, 0, 0.1, 0.2, 0.3, 0.4, and 0.5. The influence of different axial compression ratios on the seismic performance of the joints under bidirectional horizontal loading was analyzed. The results showed that when subjected to tension-bending and pure bending, the joints ultimately exhibited tensile failure of the flange high-strength bolts; when subjected to compression-bending with an the axial compression ratio of 0.1, the joints ultimately still failed due to tensile failure of the flange high-strength bolts, whereas when the axial compression ratio ranged from 0.2 to 0.5, the failure occurred at the connection between the lower column and the column base stiffener. Under tension-bending condition, the flange plates, flange high-strength bolts, and the lower section of the core tube bore substantial loads, while the load-transfer capacity of the joints was relatively weak, resulting in less load being transferred to the lower column. During severe earthquakes, when the structural elastic-plastic inter-story drift angle reached the limit value of 0.02 rad, excessive tensile deformation of the flange high-strength bolts led to joint failure. In practical engineering, special attention should be paid to the design of flanges and high-strength bolts for scenarios where tension or excessive seismic intensity may occur. Under pure bending and compression-bending loading, as the axial compression ratio increased, the bearing capacities of the flange plates, flange high-strength bolts, and the lower section of the core tube decreased, while the bearing capacity of the lower column increased. Concurrently, the joints' load-transfer capacity, energy dissipation capacity, and ductility were enhanced, but the overall bearing capacity decreased and stiffness degradation accelerated. When the axial compression ratio was 0, the joints had the highest bearing capacity, but relatively weak energy dissipation capacity, and ultimately underwent joint failure. Therefore, it is recommended to control the axial compression ratio at 0.2 in joint design, to ensure the joint possesses both high bearing capacity and favorable ductility and energy dissipation capacity.
-
[1] 张爱林,张艳霞.工业化装配式高层钢结构新体系关键问题研究和展望[J].北京建筑大学学报,2016,32(3):21-28. [2] 郁银泉,朱峰岐,王喆.钢结构建筑的推广与应用综述(英文)[J].钢结构(中英文),2020,35(1):59-69. [3] 卫泽强.新型装配式钢结构柱-柱节点抗震性能及局部锈蚀研究[D].太原:太原理工大学,2024. [4] 郭冬梅,王元清,伊永成.装配式多层钢结构柱-柱连接的研究与展望[J].交通科技与经济,2019,21(6):64-68. [5] 刘学春,和心宁,张爱林,等.拉-弯-剪组合作用下法兰连接方钢管柱受力性能研究[J].建筑结构学报,2018,39(6):69-80. [6] Liu X C,He X N,Wang H X,et al. Compression-bend-shearing performance of column-to-column bolted-flange connections in prefabricated multi-high-rise steel structures[J]. Engineering Structures,2018,160:439-460. [7] Liu X C,He X N,Wang H X,et al. Bending-shear performance of column-to-column bolted-flange connections in prefabricated multi-high-rise steel structures[J]. Journal of Constructional Steel Research,2018,145:28-48. [8] 孙鹏,王元清,石永久,等.方钢管法兰连接承载性能的有限元分析[J].中北大学学报(自然科学版),2009,30(5):430-435. [9] 王元清,宗亮,石永久.钢管结构法兰连接节点抗弯承载性能的试验研究[J].湖南大学学报(自然科学版),2011,38(7):13-19. [10] Wang Y Q,Zong L,Shi Y J. Bending behavior and design model of bolted flange-plate connection[J]. Journal of Constructional Steel Research,2013,84(5):1-16. [11] 丁娟,杨彬,李瑞锋,等.采用钢板攻丝高强螺栓法兰连接的装配式钢框架柱受力性能研究[J].建筑结构学报,2016,37(8):143-150. [12] 刘康,李国强,孙健运,等.方钢管柱内套筒柱-柱螺栓拼接节点受力性能试验研究[J].工业建筑,2018,48(5):37-44. [13] Li D X,Uy B,Patel V,et al. Behaviour and design of demountable steel column-column connections[J]. Steel and Composite Structures,2016,22(2):429-448. [14] Li D X,Uy B,Patel V,et al. Behaviour and design of demountable CFST column-column connections subjected to compression[J]. Journal of Constructional Steel Research,2018,141:262-274. [15] 张艳霞,金博文,黄哲文,等.装配式钢结构箱形柱塞焊-芯筒式法兰连接性能试验研究[J].工程力学,2022,39(2):110-122. [16] 张艳霞,王旭东,赵曦,等.箱形柱塞焊与单向螺栓芯筒式连接节点性能试验对比研究[J].工程力学,2021,38(10):103-118. [17] Zhang A L,Chen X D,Zhang Y X,et al. Experimental and theoretical investigation of prefabricated separated core tube flange column connection joint[J]. Journal of Constructional Steel Research,2023,201:107694. [18] 林晓俊,张爱林,张艳霞,等.方钢管混凝土柱全螺栓装配式连接节点抗震性能数值分析[J].建筑钢结构进展,2025,27(4):56-68. [19] 张艳霞,程梦瑶,张爱林,等.箱形柱整体芯筒式全螺栓连接受力性能研究[J].建筑结构学报,2020,41(5):180-189. [20] 中国钢结构协会.多高层建筑全螺栓连接装配式钢结构技术标准:T/C SCS 012―2021[S].北京:中国建筑工业出版社,2021. [21] 石永久,王萌,王元清.循环荷载作用下结构钢材本构关系试验研究[J].建筑材料学报,2012,15(3):293-300. [22] D’Aniello M,Cassiano D,Landolfo R. Simplified criteria for finite element modelling of European preloadable bolts[J]. Steel and Composite Structures,2017,24(6):643-658. [23] Zhang A L,Lin Z Q,Zhang Y X,et al. Seismic performance of self-tapping bolts-octagonal core sleeve flange square steel column connection[J]. Journal of Constructional Steel Research,2025,225:109157. -
