Equivalent Bending Moment Factors for Out-of-Plane Stability Calculation Considering Sway-Frame Buckling
-
摘要: 对设有钢筋混凝土楼板的多层框架这样一种应用场景下的框架柱发生平面外的弯扭屈曲时的等效弯矩系数取值进行分析,这种框架柱的特点是可发生侧移,但上下端的扭转角为0。利用精确的总势能原理推导了平衡微分方程和边界条件,分析模型中引入了柱顶的平面外侧移刚度,并将其弹性能纳入总势能。推导发现,两端弯曲简支和扭转角等于零,将迫使柱顶侧移等于0,使简化后的总势能表达式中并不出现柱顶侧移弹簧项,从而验证了侧移刚度对框架柱单纯受弯时的平面外稳定没有影响。取三项正弦函数作为试解函数代入简化后的总势能得到了等效弯矩系数,并给出了屈曲波形。分析得到该等效弯矩系数与框架柱不发生侧移屈曲时的等效弯矩系数相同,最后通过有限元分析的屈曲结果和早期的研究成果辅助论证了该结论的正确性。Abstract: An analysis was conducted to determine the equivalent bending moment factor for out-of-plane flexural-torsional buckling of frame columns in multi-story buildings with reinforced concrete floor slabs. These columns are characterized by permitted lateral sway but zero twist angles at both ends. The equilibrium differential equations and boundary conditions were derived based on the exact total potential energy principle. The model accounted for the lateral out-of-plane displacement stiffness at the column top, with its elastic energy included in the total potential energy. The derivation showed that the simply-supported ends and zero-twist-angle boundary conditions necessitated zero lateral displacement at the column top. Consequently, the sway spring term was eliminated from the simplified total potential energy expression, confirming that lateral sway stiffness does not affect the out-of-plane stability of columns under pure bending. With a three-term sine series as the trial function, the simplified total potential energy was solved to obtain the equivalent bending moment factor, and the corresponding buckling modes were also presented. The result indicated that this factor was identical to that for frame columns in a non-sway buckling scenario. The conclusion was further validated by finite element buckling analysis and supported by discussions referencing earlier research findings presented in the paper.
-
Key words:
- flexural-torsional buckling /
- equivalent bending moment factor /
- frame column /
- frame
-
[1] 中华人民共和国住房和城乡建设部. 钢结构设计标准:GB 50017—2017[S]. 北京:中国建筑工业出版社,2018. [2] European Committee for Standardization. Eurocode 3-design of steel structures-part 1-1:Generarules and rules for buildings:EN1993-1-1[S]. Brussels:European committee for stamdardization,2022. [3] American Institute of Steel Construction. Load and resistance factor design Specification for structural steel buildings:ANSI/AI SC 360-16[S]. Chicago:American Institute of Steel Construction,2016. [4] Tong G S,Chen S F. Buckling of laterally and torsionally braced beams[J]. Journal of Constructional Steel Research,1988,11(1):41-55. -
