Analysis of Tensile and Bending Resistance Factors of a Novel Internal Plug-in Self-Locking Connector for Modular Steel Structures
-
摘要: 针对提出的新型内插件自锁式节点模块化节点，通过ABAQUS有限元软件建立了节点精细化有限元模型，模拟了节点的抗拉试验和抗弯试验，并与试验作对比，检验了模型的准确性。通过参数化分析研究了节点核心部位的卡扣厚度、卡槽侧壁厚度、卡槽上壁厚度对节点抗拉性能的影响，以及节点的加劲肋尺寸、自锁核心的内插件上部长度和内插件与柱的厚度比t对抗弯性能的影响规律。结果表明：卡扣的厚度是新型内插件自锁式节点抗拉性能的主控因素，保持内插件其他尺寸不变，增加卡扣厚度可以提高节点屈服荷载20.778%；内插件长度的增加可以有效改善模块柱子的应力集中；提高内插件与柱的厚度比t可以提升节点的抗弯性能，当柱厚度为8 mm时，t由1.0提升到1.25后，节点的屈服弯矩和极限荷载分别提升了1.10%和2.93%；加劲肋长度由100 mm增长至150 mm后，节点的初始刚度和极限荷载分别增长了14.26%和17.87%，说明增加加劲肋长度可以显著提高节点的抗弯能力。Abstract: A refined finite element model of the proposed novel internal plug-in self-locking connector for modular steel structures was established in ABAQUS. Tensile and bending tests of the connector were simulated， and the results were compared with experimental data to verify the model’s accuracy. Parametric studies were conducted to investigate the influence of the buckle thickness， the slot side wall thickness， and the slot upper wall thickness on the tensile performance of the connector， as well as the effects of the stiffening rib size， the length of the upper part of the inner plug in the self-locking core， and the thickness ratio （t）of the inner plug to the column on its bending performance. The results indicated that the buckle thickness was the primary controlling factor for the tensile performance of the novel connector. Keeping other dimensions of the inner plug unchanged， increasing the buckle thickness raised the yield load by 20.778%. Increasing the length of the inner plug effectively reduced stress concentration in the modular steel column. Enhancing t improved the bending performance of the connector. Specifically， when the column thickness was 8 mm， increasing t from 1.0 to 1.25 resulted in increases of 1.10% in the yield moment and 2.93% in the ultimate load of the connector. Moreover， increasing the stiffening rib length from 100 mm to 150 mm led to growth of 14.26% in the initial stiffness and 17.87% in the ultimate load， demonstrating that longer stiffening ribs significantly enhanced the connector’s bending capacity.
-
[1] 王巍. 绿色装配式钢结构建筑体系研究与应用[J]. 建材与装饰，2023，19（11）:45- 47. [2] 段晓丹，闫禄发. 绿色装配式钢结构建筑可持续发展对策[J]. 建筑与装饰，2024（9）:169- 171. [3] 汪晖. 绿色装配式钢结构建筑可持续发展路径分析[J]. 建筑与装饰，2023（5）:184- 186. [4] 马欣伯，娄霓，冯仕章，等. 我国模块建筑的发展与应用[J]. 建设科技，2023（12）:12- 16. [5] 侯兆新，刘晓刚. 钢结构建筑产业化关键技术与示范[J]. 建筑钢结构进展，2021，23（10）:1- 11. [6] 刘立波. 模块化钢结构建筑连接节点力学性能研究[D]. 西安:西安建筑科技大学，2020 [7] Chen Z，Liu J，Yu Y. Experimental study on interior connections in modular steel buildings[J]. Engineering Structures，2017，147:625- 638. [8] 刘明扬，王燕，郏书朔. 新型模块化钢框架板式内套筒连接节点力学性能研究[J]. 钢结构，2018，33（1）:1- 5. [9] 郑天心，竺·理查德. 柱承式集成建筑模块的连接结构:CN104328839A[P]. 2015-02-04. [10] Zhao F，Yu Y，Lin S，et al. Evaluation of the working mechanisms and simplified models of endplate-type inter-module connections[J]. Structures，2021，32:562- 577. [11] 陈志华，刘佳迪，王小盾，等. 自锁榫卯式模块建筑连接节点:CN105544738A[P]. 2016-05-04. [12] 夏军武，王永瑞，徐博，等. 一种应用于模块化钢结构建筑的自锁连接节点:CN110374195A[P]. 2019-10-25. [13] Dai X，Zong L，Ding Y，et al. Experimental study on seismic behavior of a novel plug-in self-lock joint for modular steel construction[J]. Engineering Structures，2019，181:143- 164. [14] 王剑. 钢模块建筑单元间自锁连接节点力学性能研究[D]. 天津:天津大学，2022. [15] 王霄翔，陈浩，张明亮，等. 钢结构模块建筑挤压式竖向自锁连接节点设计研究[J]. 绿色建筑，2024（1）:110- 114. [16] 刘燕，田鑫鹏，刘兴旺，等. 新型钢结构模块自锁解锁式连接节点有限元分析[J]. 山东农业大学学报（自然科学版），2023，54（1）:137- 142. [17] 丁阳，邓恩峰，宗亮，等. 模块化钢结构建筑连接节点研究进展[J]. 建筑结构学报，2019，40（3）:33- 40. [18] 王晓明. 新型内插件自锁式模块化钢结构节点力学性能研究[D]. 徐州:中国矿业大学，2023. [19] 刘明扬. 模块化钢框架新型连接节点及结构力学性能研究[D]. 青岛:青岛理工大学，2018. [20] Sanches R，Mercan O，Roberts B. Experimental investigations of vertical post-tensioned connection for modular steel structures[J]. Engineering Structures，2018，175:776- 789. -
