Finite Element Analysis of the Tensile Properties of Novel Bonded Anchorages for CFRP Bars
-
摘要: 为减小黏结式内锥形锚具在碳纤维增强复合材料（CFRP）筋受力时黏结介质的滑移，提出一种新型黏结式锚具，通过设置内阶梯增大黏结介质与钢锚筒的接触面积和摩擦力，进而减小黏结介质滑移。为验证新型黏结式内阶梯形锚具的有效性，使用有限元软件ABAQUS，分别建立单筋式内锥形锚具和内阶梯形锚具的有限元模型，进行轴向拉伸性能对比研究。结果表明：相比内锥形锚具，内阶梯形锚具的极限荷载提高了10.5%，且加载端处黏结介质滑移减小了16.4%，表明所提出的新型CFRP筋黏结式锚具有更好的受力性能。在此基础上进行内阶梯形锚具的参数分析，结果表明：直筒段长度对锚具锚固性能影响最大，锚固长度次之，阶梯高度和锚杯倾角对内阶梯形锚具锚固性能影响较小；最后给出CFRP筋直径为5 mm的单筋式内阶梯形锚具主要影响参数的建议取值范围：锚固长度取180~220 mm，直筒段长度取20~40 mm，阶梯高度取4~6 mm，锚杯倾角取2°~3°。Abstract: In order to reduce the slip of the bonding medium of the bonded inner conical anchorage when the CFRP bar is stressed，a novel bonded anchorage is proposed，which increases the contact area and friction between the bonding medium and the steel anchor cylinder through the setting of an inner step，and then reduces the slip of the bonding medium. In order to verify the effectiveness of the novel bonded inner stepped anchorage，the finite element models of single-bar inner conical anchorage and inner stepped anchorage were established using finite element software ABAQUS，and a comparative study on axial tensile performance was carried out. The analysis results showed that compared with the inner conical anchorage，the ultimate load of the inner stepped anchorage had increased by 10. 5%，and the bond medium slippage at the loading end had decreased by 16. 4%，indicating that the proposed novel CFRP ribbed bonding anchorage had better mechanical properties. On the basis of this analysis of anchorage parameters，the results showed that the length of the straight section of the anchorage had the greatest influence on the anchorage performance，followed by the anchorage length；the step height and the inclination angle of the anchor cup had a smaller influence on the anchorage performance of the inner stepped anchorage. Finally，the suggested ranges of the influence parameters for single-bar stepped anchorage with a CFRP bar diameter of 5 mm are given as follows：the anchoring length is 180 to 220 mm，the straight section length is 20 to 40 mm，the step height is 4 to 6 mm，and the anchor cup inclination angle is 2° to 3°.
-
[1] 王安妮，刘晓刚，岳清瑞.碳纤维复合材料拉索的锚固体系及服役性能研究进展[J].建筑结构学报，2022，43（9）：45-54. [2] 梅葵花，李宇，贾文科，等.纤维增强复合材料缆索锚固系统研究与应用进展[J].土木工程学报，2023，56（4）：83-102. [3] 蒋田勇，方志. CFRP预应力筋夹片式锚具的试验研究[J].土木工程学报，2008，41（2）：60-69. [4] Mei K，Seracino R，Lv Z. An experimental study on bond-type anchorages for carbon fiber-reinforced polymer cables[J]. Construction and Building Materials，2016，106：584-591. [5] Schmidt W J，Bennitz A，Täljsten B，et al. Mechanical anchorage of FRP tendons-A literature review[J]. Construction and Building Materials，2012，32：110-121. [6] 朱元林，刘礼华，张继文，等. CFRP筋粘结型锚固系统数值模拟及失效分析[J].复合材料学报，2015，32（5）：1414-1419. [7] 刘荣桂，李十泉，李明君，等. CFRP筋新型锚具静载试验及有限元分析[J].工业建筑，2011，41（增刊1）：624-627. [8] 周竞洋，汪昕，解佳展，等.高强CFRP拉索-弯折锚固系统静力性能研究[J].中国公路学报，2024，37（3）：298-307. [9] 李扬，贾丽君.基于Tsai-Wu准则的CFRP拉索黏结型锚具仿真分析[J].重庆交通大学学报（自然科学版），2020，39（1）： 60-66. [10] 中国国家标准化管理委员会.预应力筋用锚具、夹具和连接器：GB/T 14370—2015[S].北京：中国标准出版社，2016. [11] Li F，Zhao L Q，Chen S H，et al. Prediction of tensile capacity based on cohesive zone model of bond anchorage for fiberreinforced polymer tendon[J]. Composite Structures，2010，92（10）：2400-2405. [12] 王梓豪，李承高，咸贵军，等.多束平行碳纤维复合材料拉索锚固系统的承载性能研究[J].工业建筑，2022，52（9）：18-27. [13] 王秋然. CFRP筋新型粘结型锚具受力性能研究[D].北京：北京工业大学，2025. -
