Comparison of Chinese and American Design Codes for Steel Frame-Braced Tube Structures
-
摘要: 为研究中美规范在钢框架-支撑筒结构设计上的差异，以北京某160.8 m的钢框架-支撑筒结构实际工程为例，分别按中美规范及相应设计习惯进行结构设计，并比较了中美规范设计模型间结构整体指标、材料用量、抗地震倒塌性能等方面的差异。结果表明：在相同的计算参数下，中美规范设计模型间结构刚度和结构整体指标相对接近；中美规范关于钢框架-支撑筒结构抗震二道防线设计的内力调整和实现方法均有较大差异，导致构件截面设计存在差异；中美规范设计模型间材料用量的分布不同，按中国规范设计模型的梁和支撑材料用量较多、柱材料用量较少，总体材料用量高4%；中国规范设计模型的抗倒塌安全储备系数约低于美国规范设计模型的7.5%。Abstract: To study the differences between Chinese and American codes in the design of steel frame-braced tube structures， a practical engineering project—a 160.8 m steel frame-braced tube structure in Beijing—was taken as an example. The structural design was carried out according to Chinese and American codes and their corresponding design habits. The differences in overall structural indicators， material consumption， and seismic collapse resistance performance were then compared between the models designed under the two codes. The results showed that， under the same calculation parameters， the structural stiffness and overall structural indicators of the models designed according to Chinese and American codes， respectively， were relatively close. There were significant differences in the internal force adjustment and implementation methods for the seismic second line of defense design of steel frame-braced tube structures between China and the United States， resulting in differences in component section design. Additionally， the distribution of material usage between the models designed by Chinese and American codes differed. In the model designed according to the Chinese code， the beam and brace material usage was higher， while the column material usage was lower， with the overall material usage being 4% higher. Furthermore， the collapse margin ratio of the model designed by the Chinese code was approximately 7.5% lower than that of the model designed by the American code.
-
[1] 中华人民共和国住房和城乡建设部. 建筑结构荷载规范：GB 50009—2012［S］. 北京：中国建筑工业出版社，2012. [2] American Society of Civil Engineers/Structural Engineering Institute. Minimum design loads and associated criteria for buildings and other structures：A SCE 7-22［S］. Reston，Virginia：American Society of Civil Engineers/Structural Engineering Institute，2022. [3] 中华人民共和国住房和城乡建设部. 高层民用建筑钢结构技术规程：JGJ 99—2015［S］. 北京：中国建筑工业出版社，2015. [4] American Institute of Steel Construction. Seismic provisions for structural steel buildings：AI SC 341-22［S］. Chicago：American Institute of Steel Construction，Inc.，2022. [5] 中华人民共和国住房和城乡建设部. 建筑抗震设计规范：GB 50011—2010［S］. 2016版. 北京：中国建筑工业出版社，2016. [6] International Code Council. International building code：IBC 2012［S］. Washington：International Code Council，2012. [7] 吕红山，赵凤新. 适用于中国场地分类的地震动反应谱放大系数［J］. 地震学报，2007，29（1）：67- 76. [8] 罗开海，王亚勇. 中美欧抗震设计规范地震动参数换算关系的研究［J］. 建筑结构，2006，36（8）：103- 107. [9] World Meteorological Organization. Guideline for converting between various wind averaging periods in tropical cyclone conditions：WMO/TD- No.1555［S］. Geneva：World Meteorological Organization，2010. [10] 周瑞. 中美房屋建筑风荷载计算对比分析［J］. 建筑结构，2023，53（增刊1）：258- 262. [11] 连尉安，张耀春. 钢支撑及框架-中心支撑双重抗侧力体系研究现状、不足及改进［J］. 地震工程与工程振动，2005，25（3）：67- 75. [12] Luco N，Cornell C A. Structure-specific scalar intensity measures for near-source and ordinary earthquake ground motions［J］. Earthquake Spectra，2007，23（2）：357- 392. [13] Federal Emergency Management Agency. HAZUS-MH2.1 technical manual［M］. Washington：Federal Emergency Management Agency，2012. [14] Applied Technology Council. Quantification of Building Seismic Performance Factors：ATC-63［S］. Redwood：Applied Technology Council，2010. -
