平单轴光伏跟踪支架多边形主梁抗扭承载性能研究

袁毅

doi:10.13206/j.gjgS24121701

平单轴光伏跟踪支架多边形主梁抗扭承载性能研究

doi: 10.13206/j.gjgS24121701

袁毅

华中科技大学土木与水利工程学院, 武汉 430074

详细信息

作者简介:
袁毅，博士研究生，研究方向为新能源结构开发与设计。Email：75388365@qq.com

计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-12-17
- 网络出版日期: 2026-04-13
- 刊出日期: 2026-02-22

Research on the Torsional Capacity of Polygonal Tubular Main Beams for Flat Single-Axis Solar Trackers

Yi Yuan

School of Civil and Hydraulic Engineering, Huazhong University of Science and Technology, Wuhan 430074, China

摘要

摘要: 平单轴结构的光伏跟踪支架为风敏感结构，风荷载的作用导致支架主梁产生较大的扭矩。美国规范中仅对矩形管和圆管截面进行了设计规定，对多边形管截面在实际工程中的应用却无明确计算依据，且国内规范尚没有钢结构抗扭设计的相关规定。根据壳单元屈曲理论、规范原理、数值模拟的方式对薄壁闭口截面的抗扭承载力进行了分析和对比。结果表明：在满足一定宽厚比条件下，理论计算结果与数值模拟结果基本一致，据此可建立相应的抗扭承载力计算公式。并进一步结合平单轴主梁的受力特点，探讨了其截面优化设计方法。
- 平单轴 /
- 抗扭承载力 /
- 屈曲 /
- 临界应力 /
- 多边形空心截面
Abstract: The flat single-axis photovoltaic （PV） tracker is a wind-sensitive structure， in which wind loads induce significant torsional moments in the main tubular beam. Current design codes， such as the AISC code， provide guidelines only for rectangular and circular tubular sections. However， they lack explicit calculation methods for polygonal tubular sections and offer no specific provisions for torsion design in steel structures （e.g.， in Chinese codes）. This study analyzed and compared the torsional capacity of thin-walled closed sections using shell buckling theory， standardized design principles， and numerical simulation. The results indicated that provided the width-to-thickness ratio requirements were satisfied， the theoretical predictions showed good agreement with the simulation results， based on which corresponding torsional capacity calculation formula was proposed. Accordingly， the cross-sectional optimization design strategies tailored to the characteristics of the flat single-axis tracker’s main tubular beam were explored.
- flat single-axis tracker /
- torsional capacity /
- buckling /
- critical stress /
- polygonal hollow section

HTML全文

参考文献(25)

[1]	David V，Valero C，Egusquiza M，et al. Failure investigation of a solar tracker due to wind-induced torsional galloping[J]. Engineering Failure Analysis，2022，135：106137.
[2]	Martínez-García E，Blanco-Marigorta E，Gayo J P，et al. Influence of inertia and aspect ratio on the torsional galloping of single-axis solar trackers[J]. Engineering Structures，2021，243：112682.
[3]	Ma W Y，Zhang W D，Zhang X B，et al. Experimental investigations on the wind load interference effects of single-axis solar tracker arrays[J]. Renewable Energy，2023，202：566- 580.
[4]	王峰，王佳盈，王子健，等. 大长宽比平单轴光伏板风荷载试验研究[J]. 湖南大学学报（自然科学版），2023，50（7）：130- 139.
[5]	胡磊. 光伏跟踪支架产品特点及发展趋势[J]. 电机技术，2021（1）：60- 64.
[6]	Liu J Z，Fang H，Chan T M. Investigations on material properties and residual stresses in cold-formed high strength steel irregular hexagonal hollow sections[J]. Thin-Walled Structures，2022，176：109220.
[7]	Liu J Z，Fang H，Chan T M. Structural behaviour of high strength steel hexagonal hollow section stub columns under axial compression[J]. Engineering Structures，2022，258：114653.
[8]	Liu J Z，FanG H，Chan T M. Experimental and numerical investigations on stub column behaviour of cold-formed high strength steel irregular octagonal hollow sections[J]. Journal of Constructional Steel Research，2022，191：107170.
[9]	尧国皇，宋宝东，黄用军. 矩形钢管弯扭构件的工作性能研究[J]. 钢结构，2008，23（9）：16- 21.
[10]	Zaifuddin S，Chen D H，Ushijima K. Estimation of maximum torsional moment for multicorner tubes[J]. Thin-Walled Structures，2017，112：66- 77.
[11]	Kim K，Yoo C H. Ultimate strengths of steel rectangular box beams subjected to combined action of bending and torsion[J]. Engineering Structures，2008，30（6）：1677- 1687.
[12]	Nakai H，Murayama Y，Kitada T，et al. An experimental study on ultimate strength of thin-walled box beams subjected to bending and torsion[J]. Journal of Structural Engineering，1990，36A：63- 70.
[13]	Rendall M A，Hancock G J，Rasmussen K J R. Modal buckling behaviour of long polygonal tubes in uniform torsion using the generalised cFSM[J]. Thin-Walled Structures，2018，128：141- 151.
[14]	White G J，Grzebieta R H，Murray N W. Maximum strength of square thin-walled sections subjected to combined loading of torsion and bending[J]. International Journal of Impact Engineering，1993，13（2）：203- 214.
[15]	American Institute of Steel Construction. Specification for structural steel buildings：ANSI/AI SC 360-16[S]. Chicago：American Institute of Steel Construction，2016.
[16]	Timoshenko S P. Theory of elastic stability[M]. New York：McGraw-Hill，1936.
[17]	中华人民共和国住房和城乡建设部. 钢结构设计标准：GB 50017—2017[S]. 北京：中国建筑工业出版社，2018.
[18]	中华人民共和国住房和城乡建设部. 冷弯薄壁型钢结构技术规范：GB 50018—2002[S]. 北京：中国计划出版社，2002.
[19]	李明昭，周竞欧. 薄壁杆结构计算[M]. 北京：高等教育出版社，1992.
[20]	符拉索夫. 薄壁空间体系的建筑力学[M]. 钟慕唐，译. 北京：建筑工业出版社（中国工业社），1957.
[21]	陈勇. 考虑剪切变形影响的开口薄壁梁约束扭转研究[D]. 长沙：长沙理工大学，2015.
[22]	European Committee for Standardization. Eurocode 3：design of steel structures-part 1-1：general rules and rules for buildings：BS EN 1993-1-1∶2005[S]. United Kingdom：European Committee for Standardization，2005.
[23]	Ziemian R D. Guide to stability design criteria for metal structures[M]. 6th ed. New York：Wiley，2010.
[24]	王立军. 受扭杆件设计[J]. 钢结构（中英文），2021，36（9）：40- 48.
[25]	Murray N W. Introduction to the theory of thin-walled structures[M]. Oxford：Clarendon Press，1984.
