Three-Dimensional Analysis Method for Steel Structure Factory Buildings with H-Section Tapered Beams and Columns
-
摘要: H形截面楔形梁柱在钢结构厂房中普遍应用,因为楔形构件匹配近似楔形变化的弯矩图可最大化发挥材料性能。GB 51022—2015《门式刚架轻型房屋钢结构技术规范》(简称《门规》)针对轻型房屋的特点,在确保安全的前提下以经济性为首要目标,对楔形梁柱的设计作了专门规定。调查表明,国内主要的钢结构分析软件,均采用二维方法进行楔形梁柱厂房的结构分析,未能充分发挥三维分析的巨大潜力。为此,依据《门规》和PKPM软件,对钢结构厂房分析方法论,楔形构件稳定设计关键点,主流软件分析算例等方面作简要展示,形成了H形截面楔形梁柱钢结构厂房的三维分析方法。分析表明:相较于二维方法,该三维分析方法显现了其广阔的适用性和高效的操作性,同时也凸显了使用者对钢结构稳定理论知识需求的必要性和紧迫性。Abstract: H-section tapered beams and columns are widely used in steel structure factory buildings because tapered members can maximize material performance by matching the approximately triangular bending moment diagram. The Technical Code for Steel Structure of Light-Weight Buildings with Gabled Frames (GB 51022-2015), considering the characteristics of light-weight buildings, has made specific provisions for the design of tapered beams and columns, with economy as the primary goal while ensuring safety. Research indicates that major domestic steel structure analysis software adoptes two-dimensional analysis for factory buildings with tapered beams and columns, failing to fully exploit the huge potential of three-dimensional analysis. Based on GB 51022-2015 and PKPM software, this paper briefly presents the analysis methodology for steel structure factory buildings, key points of stability design for tapered members, and analysis examples using mainstream software, thereby proposing a three-dimensional analysis method for factory buildings with H-section tapered beams and columns. Compared with the two-dimensional analysis method, the three-dimensional analysis method demonstrateds broad applicability and high operational efficiency, while also emphasizing the necessity and urgency for users to master knowledge of steel structure stability theory.
-
[1] 中国建筑科学研究院有限公司,北京构力科技有限公司.钢结构CAD软件技术条件[Z]. 2023. [2] 中华人民共和国住房和城乡建设部.门式刚架轻型房屋钢结构技术规范:GB 51022-2015[S].北京:中国建筑工业出版社,2016. [3] 中华人民共和国住房和城乡建设部.钢结构设计标准:GB 50017-2017[S].北京:中国建筑工业出版社,2018. [4] 童根树.钢结构的平面外稳定(修订版)[M].北京:中国建筑工业出版社,2013. -
