Design Approaches for Edge stiffeners in Steel Plate Walls
-
摘要: 通过分析钢板墙或内填混凝土多腔钢板组合墙边缘构件的设计要求,介绍了理论分析方法,从计算结果中提炼出边缘加劲肋门槛刚度的概念,计算了门槛刚度,提出了近似计算式。对于弹塑性阶段工作的钢板墙和加劲肋,借用了设有摇摆柱的框架结构的稳定设计方法,将三边支承的钢板墙看作摇摆柱,加劲肋看作框架柱,考虑加劲肋对板件的支撑作用,对边缘加劲肋的计算长度进行放大,提出了放大系数计算式。
-
关键词:
- 钢板墙 /
- 内填混凝土多腔组合墙 /
- 边缘加劲肋 /
- 计算长度放大系数
Abstract: The theoretical analysis method was introduced by examining the design requirements for steel plate walls or multi-cellular composite walls. Analytical theory was presented to determine the buckling factors. Based on the calculated results, the concept of threshold stiffness for edge stiffeners was identified, at which the plate buckled as a four-side supported plate. The threshold stiffness was calculated, and approximate equations were proposed. For steel plate walls and stiffeners in the elastic-plastic phase, the design approach for frames with leaning columns was introduced, where the three-side supported steel plate wall was treated as a leaning column and the edge stiffeners as the framed column, requiring the effective length of the stiffeners to be amplified to account for their bracing effect on the steel plate. A formula for the amplification factor was presented. -
[1] 童根树,钢结构的平面外稳定[M]. 北京:中国建筑工业出版社,2013. -
