箱形柱芯筒式双法兰连接平面框架参数化分析

张爱林; 陈嘉伟; 张艳霞; 刘安然; 倪宇博

doi:10.13206/j.gjgS24060101

箱形柱芯筒式双法兰连接平面框架参数化分析

doi: 10.13206/j.gjgS24060101

1. 北京建筑大学土木与交通工程学院, 北京 100044;
2. 北京建筑大学, 北京未来城市设计高精尖创新中心, 北京 100044;
3. 北京工业大学, 北京市高层和大跨度预应力钢结构工程技术研究中心, 北京 100124

详细信息

作者简介:
张爱林，教授，博士生导师，主要从事装配式钢结构方面的研究。Email:zhangal@bjut.edu.cn

计量
- 文章访问数: 3
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-06-01
- 网络出版日期: 2025-11-05
- 刊出日期: 2025-09-22

Parametric Analysis of Planar Frames with Box-Column Core-Barrel Double-Flange Joints

1. School of Civil and Transportation Engineering, Beijing University of Civil Engineering and Architecture, Beijing 100044, China;
2. Beijing Advanced Innovation Center for Future Urban Design, Beijing University of Civil Engineering and Architecture, Beijing 100044, China;
3. Beijing Engineering Research Center of High-Rise and Large-Span Prestressed Steel Structure, Beijing University of Technology, Beijing 100124, China

摘要

摘要: 基于带有箱形柱芯筒式双法兰连接节点的平面框架拟静力试验，通过大型通用有限元软件ABAQUS对该试验进行数值模拟，完成芯筒式双法兰连接平面框架试验与数值模拟的滞回曲线、刚度退化以及应力与应变的双向验证，水平承载力平均相差4.87%，刚度退化曲线平均相差6.96%，即试验与模拟模型结果较为接近。进而与焊接框架有限元模型进行双法兰节点刚性性能分析。在保证试验与数值模拟的前提下，进一步完成平面框架的参数化分析，建立了一组共5个平面框架的数值模型，研究芯筒长度对双法兰连接节点及平面框架滞回性能、应力与应变等的影响。结果表明：提高芯筒长度能够显著提高框架的极限抗弯承载力。芯筒式双法兰连接节点框架具有与传统焊接框架一致的力学性能，在结构计算时该节点连接方式可按刚接计算并可为装配式柱-柱连接节点设计提供借鉴。
- 刚性性能 /
- 箱形柱 /
- 双法兰 /
- 芯筒 /
- 参数化分析
Abstract: Based on the proposed static test of a plane frame with box-column core-barrel double-flange joints， a numerical simulation of the test was carried out using the large-scale general-purpose finite element software ABAQUS. The hysteresis curves， stiffness degradation， and stress-strain relationships of the plane frame with core-barrel double-flange joints were validated bidirectionally between the test and the numerical simulation. The average difference in the horizontal bearing capacity was 4.87%， and the average difference in the stiffness degradation curves was 6.96%， indicating that the test results were in good agreement with the simulation results. Subsequently， a stiffness analysis of the double-flange joint was conducted by comparing it with a finite element model of a welded frame. Under the premise of ensuring consistency between the test and numerical simulation， a parametric analysis of the plane frame was further carried out. A total of five numerical models of the plane frame were established to investigate the influence of core-barrel length on the hysteretic behavior， stress， strain， and other performance aspects of the double-flange joint and the plane frame. The results showed that increasing the core-barrel length significantly enhanced the ultimate bending capacity of the frame. The frame with core-barrel double-flange joints exhibited the same mechanical properties as the traditional welded frames. In structural calculations， this type of joint can be treated as a rigid connection， providing a reference for the design of prefabricated column-to-column joints.
- stiffness /
- box column /
- double flange /
- core-barrel /
- parametric analysis

HTML全文

参考文献(32)

[1]	薛军. 装配式预应力组合结构体系设计与工程应用[J]. 中国建筑金属结构，2023，22（7）:108-110.
[2]	Brian U，Vipulkumar P，Li D X，et al. Behaviour and design of connections for demountable steel and composite structures[J]. Structures，2017，9:1-12.
[3]	Li D X，Brian U，Farhad A，et al. Behaviour and design of demountable CFST column-column connections under tension[J]. Journal of Constructional Steel Research，2017，138:761-773.
[4]	Li D X，Brian U，Vipul P，et al. Behaviour and design of demountable CFST column-column connections subjected to compression[J]. Journal of Constructional Steel Research，2018，141:262-274.
[5]	刘学春，王玥，张爱林. 法兰连接方钢管柱-桁架焊接节点抗震性能试验研究[J]. 振动与冲击，2021，40（19）:200-211，260.
[6]	刘学春，和心宁，张爱林，等. 拉-弯-剪组合作用下法兰连接方钢管柱受力性能研究[J]. 建筑结构学报，2018，39（6）:69-80.
[7]	刘学春，崔小雄，张爱林，等. 修复后方钢管柱与H型钢梁全螺栓双夹板连接节点抗震性能试验研究[J]. 建筑结构学报，2018，39（11）:39-47.
[8]	Liu X，He X，Wang H，et al. Compression-bend-shearing performance of column-to-column bolted-flange connections in prefabricated multi-high-rise steel structures[J]. Engineering Structures，2018，160:439-460.
[9]	Liu X，He X，Wang H，et al. Bending-shear performance of column-to-column bolted-flange connections in prefabricated multi-high-rise steel structures[J]. Journal of Constructional Steel Research，2018，145:28-48.
[10]	Liu X，Zhan X，Pu S，et al. Seismic performance study on slipping bolted truss-to-column connections in modularized prefabricated steel structures[J]. Engineering Structures，2018，163:241-254.
[11]	Nikolai V，Rafkat G，Aleksandr T. Flange connections with high-strength bolts with technological heredity of bolts[J]. Magazine of Civil Engineering，2021，7（99）:9912.
[12]	Dhanapal J，Ghaednia H，Das S，et al. Structural performance of state-of-the-art VectorBloc modular connector under axial loads[J]. Engineering Structures，2019，183:496-509.
[13]	舒兴平，钱鑫，刘筱钰，等. 装配式钢框架柱法兰栓焊连接节点受力性能试验研究与有限元分析[J]. 建筑结构，2023，53（5）:90-97.
[14]	Shi F W，Li Y M. Innovative inner sleeve composite bolted connections for modular steel constructions:experimental and numerical studies[J]. Journal of Building Engineering，2023，64，105624.
[15]	Farajian M，Sharafi P，Alembagheri M，et al. Effects of bolted connections’properties on natural dynamic characteristics of corner-supported modular steel buildings[J]. Structures，2022，45:1491-1515.
[16]	Zhang A L，Xie Z，Zhang Y X，et al. Shaking table test of a prefabricated steel frame structure with all-bolted connections[J]. Engineering Structures，2021，248，113273.
[17]	Zhang Y X，Huang Z W，Li Y L，et al. Experimental and numerical investigation of prefabricated prestressed vertical steel strand core tube flange column connection joint[J]. Journal of Constructional Steel Research，2022，190，107124.
[18]	张艳霞，程梦瑶，张爱林，等. 箱形柱整体芯筒式全螺栓连接受力性能研究[J]. 建筑结构学报，2020，41（5）:180-189.
[19]	张艳霞，侯兆新，张爱林，等. 箱形钢柱螺栓连接节点试验研究[J]. 钢结构（中英文），2021，36（1）:34-49.
[20]	张艳霞，黄哲文，金博文，等. 装配式竖索自攻螺栓-芯筒法兰柱节点性能分析[J]. 建筑结构，2021，51（增刊2）:1222-1227.
[21]	张艳霞，金博文，黄哲文，等. 塞焊设置对箱形柱芯筒式法兰连接节点性能影响的试验研究[J]. 建筑结构，2021，51（增刊2）:828-833.
[22]	张艳霞，王旭东，赵曦，等. 箱形柱塞焊与单向螺栓芯筒式连接节点性能试验对比研究[J]. 工程力学，2021，38（10）:103-118.
[23]	张艳霞，金博文，黄哲文，等. 装配式钢结构箱形柱塞焊-芯筒式法兰连接性能试验研究[J]. 工程力学，2022，39（2）:110-122.
[24]	张爱林，朱莉娜，张艳霞，等. 中间柱型阻尼器全螺栓装配式钢框架数值分析[J]. 钢结构（中英文），2019，34（12）:46-51.
[25]	张艳霞，郑明召，黄威振，等. 箱形柱内套筒式全螺栓拼接节点试验数值模拟[J]. 建筑钢结构进展，2018，20（4）:34-46.
[26]	张爱林，王庆博，张艳霞，等. 芯筒式双法兰刚性连接平面及减震框架试验对比分析[J]. 工程力学，2020，37（12）:18-33.
[27]	张艳霞，武丙龙，张爱林，等. 箱形柱芯筒式双法兰连接平面框架抗震性能试验研究[J]. 建筑结构学报，2022，43（2）:29-42.
[28]	张爱林，王杰，张艳霞，等. 箱形柱芯筒式双法兰刚性连接节点平面框架拟静力试验研究[J]. 工程力学，2021，38（9）:146-160.
[29]	中国国家标准化管理委员会. 钢及钢产品力学性能试验取样位置及试样制备:GB/T 2975—2018[S]. 北京:中国标准出版社，2018.
[30]	中国国家标准化管理委员会. 金属材料拉伸试验第1部分:室温试验方法:GB/T 228.1—2021 [S]. 北京:中国标准出版社，2021.
[31]	成大先. 机械设计手册[M]. 5版. 北京:中国化学工业出版社，2010.
[32]	中华人民共和国住房和城乡建设部. 钢结构高强度螺栓连接技术规程:JGJ 82—2011[S]. 北京:中国建筑工业出版社，2010.
