Research on the Seismic Performance of Steel Frames with Self-Centering SMA Joints
-
摘要: 形状记忆合金(shape memory alloy,SMA)具有形状记忆特性和超弹性特质,将材料应用于钢结构节点中便可使结构具备自复位和耗能的能力,已有研究大多聚焦于使用SMA材料梁柱节点本身的性能,对使用SMA自复位梁柱节点的钢框架抗震性能研究较少。为研究使用SMA自复位节点的钢框架在地震作用下的性能表现,通过有限元软件OpenSEES对使用SMA自复位节点的钢框架进行建模,与试验数据对比证明简化模型的准确性;以初始抗侧刚度、承载力、层间位移角和残余层间位移角等为分析指标,对简化模型进行非线性静力分析和非线性动力分析。研究结果表明:相较传统钢框架,装配SMA自复位节点钢框架的初始抗侧刚度和承载力均更小;在不同侧向加载模式下,传统钢框架和SMA自复位节点钢框架的最大层间位移角均在结构下部,SMA自复位节点钢框架的相对层间位移角更小;由于装配了SMA自复位节点,SMA自复位节点钢框架的层间位移变形更大,但在地震作用后基本恢复到初始状态,结构产生的残余层间位移角较传统钢框架显著降低;装配该种SMA自复位节点可以改善结构层间位移离散较大的现象,使结构受力更加均匀,相对传统钢框架具有更好的抗震性能,表现出较强的震后恢复性能,提升了结构的可修复性。Abstract: Shape memory alloy (SMA) possesses the characteristics of shape memory effect and superelasticity. Applying SMA materials to steel structure joints can impart self-centering and energy dissipation capabilities to the structures. Most existing studies focus on the performance of SMA-based beam-column joints, with limited research on the seismic performance of steel frames incorporating these self-centering joints. To investigate the behavior of steel frames with self-centering SMA joints under seismic action, a numerical model was developed using the finite element software OpenSEES. The accuracy of the simplified model was validated against experimental data. Using initial lateral stiffness, bearing capacity, maximum inter-story drift ratio, and residual inter-story drift ratio as analysis indexes, both nonlinear static analysis and dynamic analysis were carried out. The results showed that, compared to the traditional steel frame, the steel frame equipped with self-centering SMA joints exhibited lower initial lateral stiffness and bearing capacity. Under different lateral loading patterns, the maximum inter-story drift ratio in both frame types occurred in the lower stories; however, the frame with SMA joints demonstrated a smaller relative inter-story drift ratio. Due to the incorporation of self-centering SMA joints, this frame experienced larger inter-story deformation. Nevertheless, it essentially returned to its initial state post-earthquake, with a significantly reduced residual inter-story drift ratio compared to the traditional frame. The application of these SMA joints mitigated the considerable dispersion of inter-story displacements, leading to a more uniform distribution of forces. Consequently, the frame with SMA joints displayed superior seismic performance and stronger post-earthquake recoverability compared to the traditional steel frame, thereby enhancing the structural reparability.
-
Key words:
- shape memory alloy /
- self-centering /
- steel frame /
- finite element model /
- seismic performance
-
[1] 吕西林,陈云,毛苑君. 结构抗震设计的新概念:可恢复功能结构[J]. 同济大学学报(自然科学版),2011,39(7):941-948. [2] 吕西林,武大洋,周颖. 可恢复功能防震结构研究进展[J]. 建筑结构学报,2019,40(2):1-15. [3] Ocel J,Desroches R,Leon T,et al. Steel beam-column connections using shape memory alloys[J]. Journal of Structural Engineering,2004,130(5):732-740. [4] Penar B. Recentering beam-column connections using shape memory alloys[D]. Atlanta,GA:Georgia Institute of Technology,2005. [5] Wang W,Fang C,Liu J. Self-centering beam-to-column connections with combined superelastic SMA bolts and steel angles[J]. Journal of Structural Engineering,2017,143(2),04016175. [6] Ma H,Wilkinson T,Cho C. Feasibility study on a self-centering beam-to-column connection by using the superelastic behavior of SMAs[J]. Smart Materials & Structures,2007,16(5),1555. [7] Ma H W,Cho C D. A numerical study on bolted end-plate connection using shape memory alloys[J]. Materials & Structures,2008,41(8):1419-1426. [8] Cheng F,Yam M,Lam A,et al. Cyclic performance of extended end-plate connections equipped with shape memory alloy bolts[J]. Journal of Constructional Steel Research,2014,94(3):122-136. [9] Garlock M,Sause R,Ricles J. Behavior and design of posttensioned steel frame systems[J]. Journal of Structural Engineering,2007,133(3):389-399. [10] Garlock M,Ricles J,Sause R. Influence of design parameters on seismi response of post-tensioned steel MRF systems[J]. Engineering Structures,2008,30(4):1037-1047. [11] 张艳霞,叶吉健,杨凡,等. 自复位钢框架结构抗震性能动力时程分析[J]. 土木工程学报,2015,48(7):30-40. [12] Gordana H,Garlock M M,Erik V. Reliability-based evaluation of design and performance of steel self-centering moment frames[J]. Journal of Constructional Steel Research,2011,67:1495-1505. [13] Vasdravellis G,Baiguera M,Al-Sammaraie D. Robustness assessment of a steel self-centering moment-resisting frame under column loss[J]. Journal of Constructional Steel Research,2018,141:36-49. [14] 姜子钦,王同宽,张文莹,等. 一种装配式自复位钢支撑结构体系的抗震性能研究[J]. 钢结构(中英文),2024,39(12):29-37. [15] 中华人民共和国住房和城乡建设部. 建筑抗震设计标准:GB/T 50011—2010[S]. 北京:中国建筑工业出版社,2024. [16] Sultana P,Youssef M. Seismic performance of steel moment resisting frames utilizing superelastic shape memory alloys[J]. Journal of Constructional Steel Research,2016,125:239-251. [17] Pacific Earthquake Engineering Research Center. PEER ground motion database[Z]. Berkeley:University of California,2013. [18] Hancock J,Watson-Lamprey J,Abrahamson N A,et al. An improved method of matching response spectra of recorded earthquake ground motion using wavelets[J]. Journal of Earthquake Engineering,2006,10(S):67-89、 -
